AFD E-Sense Flex Fuel Content Sensor

The Advanced Fuel Dynamics E-Sense Flex Fuel Content Sensor is a high-flow alternative to conventional GM/Continental ethanol content sensors. Designed for performance fuel systems, the E-Sense measures both fuel composition and temperature while offering multiple signal outputs and interchangeable fitting options for integration with a wide range of fuel system configurations.

KEY FEATURES

• Up to 12X the fuel flow capacity of a GM/Continental fuel content sensor
• High-flow design helps reduce fuel restriction and turbulence
• Interchangeable fittings support multiple fuel system configurations
• 50-150 Hz Output Range compatible with systems designed around Continental-style sensor signals
• Native 0-5V Output: 0.5V = 0% and 4.5V = 100% fuel content
• Provides both fuel content and fuel temperature data
• Temperature-compensated sensing for accurate fuel content measurement
• Compact, low-profile billet housing
• Hardened electronics using OE-quality components
• Made in the USA

FITTING COMPATIBILITY

• 5/16" OE-Style Quick Connect
• 3/8" OE-Style Quick Connect
• 1/2" OE-Style Quick Connect
• -6AN
• -8AN
• -10AN
• -12AN
• -8AN ORB

Note: Modular fitting options allow the E-Sense sensor to be configured for a wide range of performance fuel systems without requiring a separate bypass arrangement. Verify fitting size, signal compatibility, and engine management requirements before installation.
