The Texas Speed Tuner Supercharger Kit, Powered by Rotrex, is a high-output forced-induction system for GM trucks equipped with 4.8L, 5.3L, 6.0L, and 6.2L LS-based engines. Designed for combinations ranging from street-driven builds to high-horsepower applications, the system offers smooth, linear boost delivery with support for builds ranging from approximately 600 HP to 1,200+ HP, depending on configuration.

The bolt-on bracket system utilizes factory mounting locations without requiring block modifications. Boost and power output can be adjusted through supercharger pulley selection, while the smart idler arrangement allows multiple configurations to use the same belt routing.

VEHICLE FITMENT

4.8L Vortec: Gen IV LY2, L20
5.3L Vortec: Gen III LM7, L59, LM4
5.3L Vortec: Gen IV LMG, LC9, LY5, L96
6.0L Vortec: Gen III LQ4, LQ9
6.2L Vortec: Gen IV L92, L9H, L94

KIT FEATURES

CAD-Designed Bracket System utilizing factory mounting locations
Anodized Billet Pulleys
10-Rib Supercharger Belt Drive
Smart idler system designed to accommodate pulley changes without requiring different belts or additional idlers
Supercharger pulley changes allow boost and power output to be adjusted for different combinations
All required mounting hardware included

WHY ROTREX?

Compact Traction-Drive Design: Provides efficient operation and compact packaging
1900+ CFM Output: Supports applications ranging from approximately 600 HP to 1,200+ HP
Linear Boost Delivery: Provides smooth, predictable power delivery as engine speed increases
Adjustable Power Output: Boost can be changed through supercharger pulley selection
High-Speed Operation: Traction-drive system supports impeller speeds up to 90,000 RPM with an 85mm impeller
Durability: Supercharger testing includes SAE-based durability testing exceeding 160,000 miles
Self-Contained Oiling System: Internal dry-sump-style lubrication system with stated 50,000-mile service intervals

PRODUCT VIDEOS

IMPORTANT NOTES

ATI Performance Balancer is not included.
Boost and horsepower output vary based on supercharger pulley selection, engine combination, supporting modifications, fuel system, and tuning.
Proper calibration is required for the completed forced-induction combination.

Note: Verify engine, accessory-drive, and vehicle compatibility before installation. Final power capability depends on the complete engine and vehicle combination.
